TR90-15

P-Modular line

Suitable for:

Large dimension machinings with manual assembly

Ratio
1.875:1

RPM up to
2500 min-1

Max axial load
3900 N

Torque
600 Nm

Weight
110/140/180 Kg

RPM dry running
2500 min-1

Collet
ISO/BT 50

Enter your details to receive the link to the pdf catalog of this product.

Shank available

ISO 69871
ISO 40, ISO 50

MAS-BT
BT 40, BT 50

HSK
HSK 100, HSK 125, HSK 63, HSK 80, HSK 80-F

BBT
BBT 40, BBT 50

CAPTO
CAPTO C6, CAPTO C8

CAT
CAT 40, CAT 50

Output available

Collet
ER 40

Arbor output
10mm

Weldon
Ø 4mm, Ø 6mm

HSK
HSK 32

CAPTO
C3
